Safety Relief Valve

Safety Relief Valves

Reliable Overpressure Protection for Industrial Systems

Our Safety Relief Valves are precision-engineered to safeguard pipelines, pressure vessels, and process equipment by automatically releasing excess pressure. Designed for durability and compliance, these valves ensure uninterrupted operation across a wide range of industrial applications.

⚙️ Specifications

• Sizes Available:
  ½” to 4″ (DN15 to DN100)
  Custom sizes available upon request
• Pressure Range:
  0.5 bar to 400 bar (7 psi to 5800 psi)
• Material of Construction:
  • Body: Stainless Steel (SS304, SS316), Carbon Steel, Brass, Cast Iron
  • Trim: Stainless Steel, PTFE, Viton, NBR
  • Spring: Chrome Vanadium Steel or Stainless Steel
• End Connections:
  Threaded (BSP/NPT), Flanged (ANSI/DIN), Welded
• Temperature Range:
  -40°C to +250°C (depending on seal material)

✅ Features

• Factory-set or field-adjustable pressure settings
• Leak-tight sealing with corrosion-resistant internals
• Compact design for easy installation and maintenance
• ASME Section VIII and API 526 compliant
• Optional test lever and drain port configurations

🏭 Applications

• Steam boilers and compressed air systems
• Chemical and petrochemical processing
• Water treatment and HVAC systems
• Hydraulic and pneumatic circuits
